| Model | E115 |
|---|---|
| Configuration | 1 × 15-inch, 2-way, non-powered |
| Frequency Response (-6 dB) | 55 Hz – 20 kHz |
| Frequency Range (-10 dB) | 43 Hz – 20 kHz |
| Power capacity1: continuous/peak | 500 W / 2000 W |
| Sensitivity | 97 dB, 1 W @ 1 m |
| Coverage Angle | 75° conical DMT™ |
| Output2 (peak SPL @ 1 m) | 130 dB |
|
Drivers LF HF |
381 mm (15 in) driver with 89 mm (3.5 in) voice coil 38 mm (1.5 in) exit, 71 mm (2.8 in) voice coil, compression driver |
| Nominal Impedance | 8Ω |
| Cross-over | Full-range only 1.55 kHz |
| Input connectors | 2 × NL4, 1 × barrier strip |
| Enclosure | Trapezoidal, plywood, black texture paint finish. Two side-mounted handles, Perforated, powder-coated steel grille with foam lining. |
| Speaker Dimensions (W×H×D) |
420 × 716 × 445 mm 16.5 × 28.2 × 17.5 in |
| Carton Dimensions (W×H×D) |
530 × 510 × 813 mm 21 × 20 × 32 in |
| Net speaker weight | 31 kg / 68 lb |
| Shipping weight | 35.4 kg / 78 lb |
